ENGINE |
|
Type |
90° Transverse V-twin, 4-stroke, 4-valve, dual spark ignition per cylinder |
|
Cooling |
Air and oil cooled. Oil cooler with a fan and dedicated oil pump |
|
Displacement |
84.21 cu in (1,380 cc) |
|
Bore and Stroke |
4.09x 3.20 in (104 x 81.2 mm) |
|
Compression Ratio |
10.5 +/-0.5 : 1 |
|
Maximum Power |
96,6 HP (71 kW) @ 6,500 rpm |
|
Torque |
89 ft-lbs (121 Nm) of torque @ 3,000 rpm |
|
Start |
Electric single push button to start |
|
Exhaust System |
Black stainless steel, 2 in 2 with crossover and 3-way catalytic converter, double lambda probe |
|
Homologation |
DOT, EPA and CARB compliant |
|
Transmission |
Gears
6-speed transmission with overdriven 6th gear |
|
Gear ratio values |
1^ 17/38 = 1 : 2,235
2^ 20/34 = 1 : 1,700
3^ 23/31 = 1 : 1,347
4^ 26/29 = 1 : 1,115
5^ 31/30 = 1 : 0,967
6^ 30/24 = 1 : 0,800 |
|
Primary Drive |
With helical teeth (ratio 26/35 = 1: 1,346) |
|
Final Drive |
Cardan shaft and bevel gear (ratio 10/36 = 1: 3,600) |
|
Clutch |
Single plate with integrated flexible coupling |
|
|
|
|
CHASSIS |
|
ALS steel twin tube cradle frame |
|
Wheelbase |
66.93 in (1700 mm) |
|
Trail |
187 mm |
|
Headstock angle |
32° |
|
Front wheel travel |
4.24 in (107.7 mm) |
|
Rear wheel travel |
4.72 in (120 mm) |
|
Front suspension |
Hydraulic telescopic fork, Ø 1.76 in (44.8 mm) with mounting for radial callipers brakes |
|
Rear suspension |
Swingarm with double shock absorber with adjustable spring preload |
|
Front brake |
Double stainless steel floating disc Ø 12.60 in ( 320 mm ) clamps radial 4-piston opposed |
|
Rear brake |
Stainless steel floating disc Ø 11.10 ( 282 mm ), two-piston callipers |
|
|
|
|
WHEELS |
|
Aluminum alloy for tubeless tyres |
|
Front wheel rim |
3.50" x 21" |
|
Rear wheel rim |
5.50" x 16" |
|
Front tyre |
120/70 R21 62V |
|
Rear tyre |
180/60 R16 80H |
|
|
|
|
DIMENSIONS |
|
Length |
2560 mm |
|
Width |
920 mm |
|
Height |
1275 mm |
|
Seat height |
740 mm |
|
Curb weight |
341 Kg (with all fluids, battery included, without fuel) |
|
Fuel tank capacity |
5.41 +/-0.13 gal US (4.51 +/-0.11 UK gal) (20.5 +/-0.5 l)20,5 litres included 5 lt. reserve |
