Displacement |
744 cc
|
|
Bore
|
80 mm
|
|
Travel
|
74 mm
|
|
Timing system
|
2 valves with light alloy pushrods and rockers
|
|
Max Power
|
38 kW (52 HP) at 6200 rpm
|
|
Maximum torque at crankshaft
|
60 Nm at 4900 rpm
|
|
Exhaust system
|
3-way catalytic converter with double lambda probe
|
|
Cooling
|
Air
|
|
Frame:
|
double cradle tubular frame in ALS steel with detachable elements.
|
|
Wheelbase:
|
1463 mm
|
|
Trail:
|
106 mm
|
|
Headstock angle:
|
26.4°
|
|
Front suspension
|
Ø 40 mm hydraulic telescopic fork
|
|
Travel:
|
130 mm
|
|
Rear suspension
|
die cast light alloy swing arm with 2 shock absorbers with adjustable spring preload
|
|
Wheel travel:
|
93 mm (shock absorber travel 80 mm)
|
|
Front Brake
|
Ø 320 mm stainless steel floating discs, Brembo callipers with 4 differently sized opposed pistons
|
|
Rear brake
|
Ø 260 mm, stainless steel disc, floating calliper with 2 pistons
|
|
Front wheel
|
18" spoked 100/90 (110/80 R18 as alternative)
|
|
Rear wheel
|
17" spoked 130/80
|
|
Saddle height
|
770 mm
|
|
Length:
|
2,185 mm
|
|
Height:
|
1110 mm
|
|
Minimum ground clearance:
|
150 mm
|
|
Fuel tank capacity
|
21 litres (including 4 litre reserve)
|
|
Kerb weight
|
193 kg
|
|
Kerb weight *
|
213 kg
|
