ENGINE |
|
Type |
Transverse 90° V twin, two valves per cylinder (titanium intake). |
|
Cooling |
Air |
|
Engine capacity |
853 cc |
|
Bore and stroke |
84 x 77 mm |
|
Compression ratio |
10.5 : 1 |
|
Maximum power |
80 HP (59 kW) at 7,750 rpm |
|
Torque |
80 Nm at 5,000 rpm |
|
Fuel system |
Electronic injection; Ø 52 mm single throttle body, Ride- by-Wire |
|
Fuel tank capacity |
21 litres (including 5 litre reserve) |
|
Approval |
Euro 4 |
|
Consumption (WMTC cycle) |
4.9 l/100 km |
|
CO2 Emissions (WMTC cycle) |
118 g/km |
|
|
|
TRANSMISSION |
|
Clutch |
Dry single disc |
|
Transmission |
6 gears |
|
Gear ratio values |
1st 16/39 = 1: 2.437
2nd 18/32 = 1: 1.778
3rd 21/28 = 1: 1.333
4th 24/26 = 1: 1.083
5th 25/24 = 1: 0.960
6th 27/24 = 1: 0.889 |
|
|
|
CHASSIS |
|
Frame |
High strength steel tubular frame |
|
Front suspension |
41 mm hydraulic telescopic USD fork, with adjustable spring preload and hydraulic rebound |
|
Front wheel travel |
170 mm |
|
Rear suspension |
Double-sided swingarm in box-type aluminium with a single shock on the right side, withadjustable spring preload and hydraulic rebound |
|
Rear wheel travel |
170 mm |
|
Front brake |
Double 320 mm stainless steel floating discs, Brembo radial-mounted callipers with 4 opposed pistons |
|
Rear brake |
Ø 260 mm stainless steel disc, floating calliper with 2 pistons |
|
Wheels |
Spoked |
|
Front wheel rim |
2.50” x 19” |
|
Rear wheel rim |
4.25” x 17” |
|
Front tyre Rear tyre |
With air chamber 110/80 - R19” With air chamber 150/70 - R17” |
|
|
|
ELECTRICAL SYSTEM |
|
A/C generator |
430 W |
|
System voltage |
12 V |
|
Battery |
12 V – 12 Ah |
|
|
|
DIMENSIONS |
|
Saddle height |
830 mm |
|
Dry weight |
208 kg |
|
Kerb weight* |
229 kg |
|
* Weight with motorcycle ready for use, with all operating fluids and 90% fuel. |
