Chassis |
ALS steel twin tube cradle frame
|
|
Wheelbase
|
1465 mm
|
|
Trail
|
116,1 mm
|
|
Headstock angle
|
26.4°
|
|
Steering angle
|
38°
|
|
Front suspension
|
traditional fork, Ø 40 mm
|
|
Front wheel travel
|
130 mm
|
|
Rear suspension
|
swingarm with double shock absorber with adjustable spring preload.
|
|
Rear wheel travel
|
97 mm
|
|
Front brake
|
stainless steel floating disc, Ø 320 mm Brembo opposed four-piston callipers
|
|
Rear brake
|
stainless steel floating disc, Ø 260 mm opposed two-piston callipers
|
|
Wheels
|
aluminium alloy
|
|
Front wheel rim
|
3,50” x 16”
|
|
Rear wheel rim
|
4.00” x 16”
|
|
Front tyre
|
130/90 - 16”
|
|
Rear tyre
|
150/80 B 16”
|
|
|
|
|
ELECTRICAL SYSTEM
|
|
|
System voltage
|
12 V
|
|
Battery
|
12V - 18 Ah
|
|
|
|
|
DIMENSIONS
|
|
|
Length
|
2185 mm
|
|
Width
|
840 mm
|
|
Height
|
1160 mm
|
|
Saddle height
|
780 mm
|
|
Kerb weight *
|
199 Kg
|
|
Fuel tank capacity
|
15 litres
|
|
Reserve
|
4 litres
|
* Weight of bike ready to ride, will all fluids and no fuel
.
